Tiny house

Homes

Design

Tiny House

Price

£1000 per m2

Size Range

10m2 - 30m2

Why a tiny house? Are you looking for a home that suits a self-sufficient, adventurous lifestyle? The U-build system is perfect for creating compact living layouts with built in furniture from sustainable materials.  They are lightweight and can be fitted to exact trailer dimensions.

U-Build is a sustainably minded company and we believe that good buildings should make both people and the planet happy! All our materials are chosen for their performance and their sustainability, and our boxes are designed to come apart again so they can have many lives.

Boxes & fixings

Read More About Boxes & fixings

Our structural boxes that create the walls, roof and floor are made from 18mm WISA Spruce plywood as standard, this is FSC certified and PEFC rated. Click here to see a typical Spruce sheet.

Or you can upgrade to WISA Birch, a harder wood (and heavier) option but with a less knotty aesthetic. See here for an example.

To fix the boxes together we will supply you with zinc plated bolts, nuts, screws and washers, as well as stainless steel wood screws.

Your pod will be supported by our specialist, height-adjustable decking risers. Each foot can support up to 1 tonne. They are made from 90% recycled plastic and fully recyclable.

Insulation

Read More About Insulation

To keep you warm and cosy we provide sheep’s wool, selected for being British based, a natural and breathable eco-friendly insulation for the walls and floor. It is building regulation compliant, contains a borax based fire retardant and does not require the addition of an insecticide. We can also use wood fibre (or most other insulation types).



To insulate the roof, we use a PIR insulation board, chosen for its high performance within 2.5m permitted development height. If you are willing to make the building slightly higher, we can swap this for a wood fibre board.

Membranes & Tapes

Read More About Membranes & Tapes

A damp-proof membrane functions like a raincoat; it will keep you the rain out whilst also allowing moisture to breathe.

For the walls and floor, we use a UV stable and fire rated membrane from Illbruck

For the roof Butyl membrane; a UV-stable, non-toxic and has a working life of up to 50 years with a 20 year supplier guarantee. An added bonus is that this arrives green roof ready, so you can add your plant layer straight-away.

Cladding

Read More About Cladding

Cladding is the material that you see on the exterior of your U-Building. It acts as a ‘rain screen’ to protect the waterproof membrane behind from damage, and completes the external appearance.

You can use any cladding you like with U-Build, but to make things simple we supply Western Red Cedar, Douglas Fir or Larch depending on availability. We choose UK grown timber with a durability class of 3, an estimated life expectancy of 15-30 years above ground, plus it looks and smells beautiful. We use 45x25mm strips that arrive as linear lengths to be cut down to length on site.

If you would like to install the cladding in a ‘herringbone’ or ‘chevron’ pattern we have a developed a cladding panel making workflow for you to follow.

Cladding panels means that no screws are visible on the front face, and the panels are easy to take off individually for maintenance. Our in house developed software (known affectionately as AutoCLAD) works out the number, length and shape of the different parts and creates a cutting list, which are either be sent for you / carpenter to produce from scratch or cut to length here. To keep the ‘U’ in U-Build, we encourage people to try assembling the panels, and you can also buy one of our specially designed cladding jigs to help with this.

If you like this style but are conscious of time and budget, one idea to save time and costs is to use herringbone cladding for the front only, and use horizontal timber for the back and sides.



Weight

We are able to provide calculations of the weight of the pod, so that you can find the right trailer for your tiny house project. Previous clients have used agricultural trailers which are able to take large amounts of weight, and are also used to being towed into position across fields.

Our services include:

  • Design consultancy
  • Producing planning drawings
  • Bespoke furniture
  • On-site building assistance
  • We can work with your chosen designer, architect or builder.

See below for a list of FAQ’s and things to consider before embarking on your build!

Road Legalities

Size and weight has to be considered for tiny homes. The below article contains some indicative information for UK roads:

Wide Loads On UK Roads – What Is The Maximum Size/Weight Allowed? (ntex.co.uk)

Planning Permission

If your building is on wheels and is classed as a caravan it may not need planning permission. There is more information included on the definition of a Caravan in the Uk’s 1968 Caravan Act. The below article gives more information:

Can I Put a Touring Caravan on My Land? | Caravan Helper





Services

Although we do not provide plumbing and electric services, we can work with your chosen tradesperson and even include hole for plug sockets.

Step 1

Initial enquiry

Step 2

Book a consultation

Our design consultations last around an hour, where our friendly team will model up your designs with you live via a video call. This is also your chance to ask those more detailed or technical questions and bounce ideas with us.

We follow this up with dimensioned layout drawings and an accurate cost estimate.

Step 3

Lets get things moving!

We will contact you to arrange an initial consultation meeting, and help you plan for the arrival of your new cabin!
